Specification
Model No. |
SL-XQ405512 01 |
SL-XQ407520 01 |
SL-XQ409540 01 |
Watt (±10%) |
2*6W |
2*8W |
2*15W |
2*7W |
2*12W |
2*20W |
Dimension |
104*52*H76mm |
144*72*H90mm |
184*92*H115mm |
Cutout |
105*53mm |
145*73mm |
185*93mm |
CCT |
2700K/3000K/3500K/4000K/5000K |
CRI |
Ra90/Ra95 |
IP Rating |
IP20 /IP44 |
Install style |
Recessed |
Optional Control |
Triac/0-10V/DALI |
Operating temperature |
-20℃-+40℃ |
Beam Angle |
15°/24°/36°/50° |
Ouput voltage |
220-240V 50/60Hz |
Material |
Die-Casting Aluminum |
Control |
On/Off |
Housing Color |
White/Black |
Certificate |
CE |
Warranty |
3 years |
Applications |
Hotels,Villa,Culbs, Restaurants, Offices, Shops, Home,etc. |
Features
- Family Design,Round Type And Square Type Recessed Anti Glare Downlights Single-Double-Triple Head Downlights Available To Choose.Suitable for Different Lighting Projects Interior Lighting Desgin.
- Adjustable Downlight Lamp Head Design, Lamp Body 355° Horizontally Rotatable,0° ~ 30° Tilting. Down Ward Lighting Or Wash Wall Lighting ,Easy To Set The Lighting Directions.
- Ultra Low Glare, Anti-Glare Design To Protect Eyes From Dazzling Lighting,Led Source Deep Hide ,Darken Nickel Color Reflector No Dazzl Lighting.
- Colorful Secondary Optic Reflector For Choose According To Room Decoration Style,Sand Silver/Sand Gold,Mass White/Black, And Uv Electropaint Darken Nickel/Gold/Chrome For Choose.
- Optical Flexibility 15/24/36/50 Degree Beam Angle, Optic Lens High Transmittance ,Provide Soft Light, Wide Application Range .
- Ra90/95 High Color Rendering Is More Realistic, Perfect For Paintings Lighting On The Wall .
- CCT Rang 2700K/3000K/3500K/4000K/5000K/5500K,Create Different Atmospheres According To The Different Needs Of The Space.
- Using International High Quality Led ChipW ith High Brightness, Long Life,.
- Die-Casting Aluminum Lamp Housing ,High-Quality Aluminum Material With Excellent Thermal Dissipation.
- Constant Current Driver Output With Flicker Free,Led Driver Efficiency 85-90% ,Provide Uniform Light, Comfortable Visual Experience .
- CCT Changeable By Switch On Led Driver ,With 3000K 4000K 5000K -3 Color Temperature In 1 Lamp For Options To Meet The Needs Of Different Scene Styles .
Application Scenarios
Widely Use In Commercial And Residential Lighting, Like Hotels, Villa,Culbs, Restaurants, Offices, Shops And Home, Etc.
