Specification
Model |
Power |
IP Rating |
Size MM |
SL-SD02-3B |
3W |
IP66 |
ф32*H70mm |
SL-SD03-6B |
5W |
IP66 |
ф45*H80mm |
SL-SD05-9B |
8W |
IP66 |
ф60*H125mm |
SL-SD06-12B |
12W |
IP66 |
ф80*H127mm |
SL-SD07-15B |
15W |
IP66 |
ф90*H120mm |
SL-SD07-18B |
18W |
IP66 |
ф90*H120mm |
SL-SD07-20B |
20W |
IP66 |
ф90*H120mm |
SL-SD08-24B |
24W |
IP66 |
ф120*H140mm |
SL-SD08-30B |
30W |
IP66 |
ф120*H140mm |
CCT |
2200K-6500K |
CRI |
Ra90/80 |
IP Rating |
IP66 |
Install style |
Surface Plate And Spike Ground |
Operating temperature |
-40℃-+60℃ |
Beam Angle |
15°/24°/36°/45° /60° |
Ouput voltage |
DC24V / AC 220-240V |
Material |
Aluminum,Tempered Glass |
Housing Color |
Sand Grey/Sand Black |
Certificate |
CE |
Warranty |
3 years |
Applications |
Central Park ,Parterre ,Garden Tree Decoration Lighting |
Features
- SEENlamp Factory Proivde Total 6 Size Of This Series Anti Glare Outdoor Led Spike Spotlights Power From 3W-30W.
- Waterproof Desing IP Rating 66 To Protect The Led Spotights From Water And Rain.Suitable For Outdoor Architecture Lighting And Landscape Lighting
- High Quality Aluminum Lamp Housing, Aluminum Material Heat Sink With Excellent Thermal Dissipation.
- Lamp Head Adjustable Design,Can Be 0° ~ 270° Tilting, And Rotatable Free.Easy Change The Lighting Directions According To Needs.
- Using International Famous Brand CREE/OSRAM Led Chip With High Brightness, Long Life, Small Light Decay.
- Optical Lens With 15°/24°/36°/45°/60° Beam Angle Available,Customers Can Decide To Select Narrow Angle ,Middle Angle Or Wide Angle To Lighting The Tree Or Objects.
- With A Hat Anti Glare Design,Avoding Direct Lighting To Harm Eyes. And Can Add Honeycomb To Make Low UGR.
- Ra90 High Color Rendering Is More Realistic, Present A Vivid Colorful World.
- CCT Range 2700K/3000K/3500K/4000K/5000K,Can Be Support The Lighting Design To Create Different Lighting Atmospheres .
- Thick Tempered Glass Cover,Adapt To Outdoor Envirment ,And High Transmittance Of Lighting.
- Input Voltage Low DC24V And AC220V-240V Both Available.
- Easy Installation Surface Mounted Or Spike Into Ground, Avioding Troubles And Save Time .Perfect For Outdoor Garden Lighting.
Application Scenarios
Widely Used Outdoor Landscape Lighting,Such As Central Park ,Parterre ,Garden Tree Decoration Lighting ,etc.
