Specification
Model No. |
SL-SD35510 |
SL-SD35520 |
SL-SD35530 |
Watt (±10%) |
10W |
20W |
30W |
Dimension |
L150*W45*H42 mm |
L285*W45*H42 mm |
L418*W45*H42 mm |
Cutout |
L142*W35mm |
L275*W35mm |
L408*W35mm |
CCT |
2700K/3000K/3500K/4000K/5000K |
CRI |
Ra90 |
IP Rating |
IP20 |
Install style |
Recessed |
Optional Control |
Triac/0-10V/DALI |
Operating temperature |
-20℃-+40℃ |
Beam Angle |
15°/24°/36° |
Ouput voltage |
220-240V 50/60Hz |
Material |
Die-Casting Aluminum |
Control |
On/Off |
Housing Color |
White/Black |
Certificate |
CE |
Warranty |
3 years |
Applications |
Hotels,Villa,Culbs, Restaurants, Offices, Shops, Home,etc. |
Features
- High Transmittance Optic Lens, Optical Flexibility 15/24/36 Degree Beam Angle .
- Ra90 High Color Rendering Is More Realistic, Restores The True Color Of The Subject.
- Glareless, Exquisite And Dexterous Design Ensure Highly Integrated In Installation Space.
- CCT Range 2700K/3000K/4000K/5000K,Provide Atmospheres Lighting According To Demand Of User Freedomly.
- Optic Len Output Oval Distribution , Especially Suitable For Lighting Long And Narrow Spaces, Such As Corridors Or Passage Areas,And Kitchen Island Or Dinning Table .
- Die-Casting Aluminum Lamp Housing ,Strong and Durable Structure, Anti-Corrosion And Anti-Rust,Powder Costing Finish White and Black.
- Using International Famous Brand Led Chip With High Brightness, Long Life, Small Light Decay, And Good Heat Dissipation Effect.
- Seenlamp Laser Blade Light Series,Inclusded Recessed Installtion Series,Frameless Type Series,Adjustable Type Series, And Surface Mounted Series Led Linear Lights.
- Constant Current Driver Output With Flicker Free,Led Driver Efficiency 85-90% ,Achieves Stable Working Performance .
- Sand White Or Sand Black Color Lamp Body Finishing ,Surface Treatment With Excellent Texture Feeling.Perfet Suitable For High End Projects Lighting .
Application
Widely Used In Commercial Lighting Like Hotels, Villas, Offices, And Residental Lighting,Etc.Sepcially Suitable For Corridors Or Passage Areas.
