Specification
Model No. |
SL-8265D-3W |
SL-8265D-6W |
Watt (±10%) |
3W |
6W |
Dimension |
Φ82*H65mm |
Φ82*H65mm |
Cutout |
Φ75mm |
Φ75mm |
CCT |
2200K-6500K |
CRI |
Ra90 |
IP Rating |
IP66 |
Install style |
Recessed (Aluminum Mounting Sleeve Included) |
Operating temperature |
-40℃-+60℃ |
Beam Angle |
15°/30°/60° |
Ouput voltage |
DC24V / AC220-240V |
Material |
6063 Aluminum,Tempered Glass, 316 Stainless Steel |
Control |
On/Off / |
Housing Color |
Stainless Steel Color + Black |
Certificate |
CE |
Warranty |
2-3 years |
Applications |
Hotels,Villa,Garden ,Corrider,Pathway , Plaza, etc. |
Features
- SEENlamp Factory Produce Multiple Size,Power,Voltage,Control Model Of Led Underground Lights Outdoor Lighting For Customer Optional.
- Outdoor Lighting Use Recessed Ground Deck Spotlights Made Of 316 Stainless Steel And 6063 Aluminum High Quality Materials,Products Eco-Friendly, Uv-Resistant And Durable.Suitable For Outdoor Architecture Lighting And Garden Landscape Lighting.
- Waterproof Desing IP Rating 66/68 To Protect The Lamp From Water And Rain, It Can Adapt To The Harsh Outdoor Environment Temperature Climate Changed All Around The Year.
- Stainless Steel Panel ,Aluminum Embedded Parts And Special Underwater Waterproof Cable Make It More Convenient For User To Install And Remove The Led Underground Lights.
- The Stainless Steel Panel Of The Led Underground Spotlights Is Flush With The Ground Floor And Will Not Affect Normal Walking. The Thicked Tempered Glass Will Not Affect The Lighting Effection ,And Also Safe For People Walk On It.
- Support To Provide Control System DMX512 Console,Controller,Decode RGB Controller, IR Romote Controller, Signal Amplifier,Led Adapter,Driver.Power Supply Etc
- Using International Famous Brand CREE Osram Led Chip With High Brightness, Long Life, Small Light Decay.
- Optical Lens With 10°/20°/30°/45°/60° Beam Angle Available,Ra90 High Color Rendering Is More Realistic, Present A Vivid Colorful World.
- CCT Range 2200K-6500K,Can Be Support The Lighting Designer To Create Different Lighting Atmospheres According To The Demand Of Building.
Application Scenarios
Widely Used Outdoor City Architectural Lighting And Garden Landscape Lighting ,Such As Hotels, Shopping Mall, Park ,Corrider,Pathway , plaza,Decoration Lighting ,Etc.
